Ball Bearing Cam Cleat - Small

Ball Bearing Cam Cleat - Small

£33.68 ex VAT £40.42 inc VAT
ex VAT £0.00 inc VAT £33.68 ex VAT £40.42 inc VAT
Sale Sold out
Shipping calculated at checkout.

Available on back order(Can be backordered)

Require larger quantities? Contact us

Stockists

Delivery

Fast UK delivery from £4.50 or FREE when spending over £100.
More Info

View full details
Product Datasheet Download Product Datasheet Download

Description

Ball Bearing Cam Cleat - Small

Designed for fast-running control lines, this Small Ball Bearing Cam Cleat delivers smooth, reliable performance and precise line control. Manufactured from die-cast aluminium, it offers higher working loads and increased durability compared to Allenite alternatives, making it ideal for demanding sailing applications.

Twin rows of ball bearings and double coil springs provide exceptionally smooth cam action and consistent cleating performance, while the optimised jaw profile reduces rope wear and allows for easy rope entry and release. Ideal for spinnaker halyards, mainsheets, jib sheets, and other high-performance control systems.

Key Features:

  • Small aluminium ball bearing cam cleat
  • Die-cast aluminium jaws and base
  • Twin rows of ball bearings for smooth operation
  • Double coil springs for consistent cam action
  • Optimised jaw profile reduces rope wear
  • Higher working loads than equivalent Allenite cam cleats
  • Ideal for fast-running control lines
  • Suitable for dinghies, keelboats, and yachts
  • Durable dark grey finish

2025 Update:

  • Updated dark grey base and cap for a modern appearance
  • Refined jaw spring tension for easier line engagement
  • Improved handling, particularly in lighter wind conditions
Bearing type Ball Bearing
Brand Allen
Fixing hole diameter mm 4
Height mm 22
Hole pitch mm 28
Iges GenericFileDrop
Iges file link https://abassets.ams3.digitaloceanspaces.com/iges/a--77.igs
Material Aluminium
Maximum line diameter mm 6
Maximum working load kg 100
Pdf GenericFileDrop
Pdf ref link https://abassets.ams3.digitaloceanspaces.com/product_files/a--77-ref.pdf
Related collection CollectionDrop
Short description Ball Bearing Cam Cleat - Small
Width mm 48
Youtube key 1 3Ctwmm2QJiI
Swipe
SKU Title Fixing Hole Dia mm Height mm Hole Pitch mm Max Line Dia mm Max Working Load Kg Weight (g) Price
A.676

Allenite Cam Cleat - Medium

 5 29 38 10 130 36
£26.13 ex VAT £31.36 inc VAT
ex VAT £0.00 inc VAT £26.13 ex VAT £31.36 inc VAT
A.677

Allenite Cam Cleat - Small

 4 22 28 6 80 23
£20.88 ex VAT £25.06 inc VAT
ex VAT £0.00 inc VAT £20.88 ex VAT £25.06 inc VAT
A.676-496

Allenite Cam Cleat With Mega Pro Lead - Medium

 5 48 38 10 130 73
£41.14 ex VAT £49.37 inc VAT
ex VAT £0.00 inc VAT £41.14 ex VAT £49.37 inc VAT
A.677-497

Allenite Cam Cleat With Mega Pro Lead - Small

 4 39 28 6 80 45
£35.32 ex VAT £42.38 inc VAT
ex VAT £0.00 inc VAT £35.32 ex VAT £42.38 inc VAT
A..76

Ball Bearing Cam Cleat - Medium

 5 29 38 10 150 64
£40.15 ex VAT £48.18 inc VAT
ex VAT £0.00 inc VAT £40.15 ex VAT £48.18 inc VAT
A..77

Ball Bearing Cam Cleat - Small

 4 22 28 6 100 27
£33.68 ex VAT £40.42 inc VAT
ex VAT £0.00 inc VAT £33.68 ex VAT £40.42 inc VAT
A..76-496

Ball Bearing Cam Cleat With Mega Pro Lead - Medium

 5 48 38 10 150 104
£50.96 ex VAT £61.15 inc VAT
ex VAT £0.00 inc VAT £50.96 ex VAT £61.15 inc VAT
A..77-497

Ball Bearing Cam Cleat With Mega Pro Lead - Small

 4 39 28 6 100 50
£47.71 ex VAT £57.25 inc VAT
ex VAT £0.00 inc VAT £47.71 ex VAT £57.25 inc VAT
A5848

Laser Control Line Cleats With Base

 5 56 67 6 100 141
£94.52 ex VAT £113.42 inc VAT
ex VAT £0.00 inc VAT £94.52 ex VAT £113.42 inc VAT
A5861

Laser Lower Vang Unit

 5 82 - 6 - 200
£149.34 ex VAT £179.21 inc VAT
ex VAT £0.00 inc VAT £149.34 ex VAT £179.21 inc VAT
A4077

Stainless Steel Base Cam Cleat - Medium

 5 18 38 12 60 36
£19.60 ex VAT £23.52 inc VAT
ex VAT £0.00 inc VAT £19.60 ex VAT £23.52 inc VAT
A4476

Stainless Steel Base Cam Cleat - Small

 4 10 26 6 40 18
£27.01 ex VAT £32.41 inc VAT
ex VAT £0.00 inc VAT £27.01 ex VAT £32.41 inc VAT
