Spinnaker
For ultimate control on the kite sheets, Team Allen sailors suggest using a standard A2030 – 30mm dynamic single – This way you get the ultimate control and feel of the kite. If you don’t feel confident not having a ratchet, try the A2140 – Switchable ratchet – instead. Alternatively, you can try the A2345 – 45mm AutoRatchet – if you prefer to have the sheets run more freely during a gybe.
For a brief rigging guide check out the video below with World Champion and Team Allen sailor, Ben Hutton-Penman.
Mast Step and Crew Area
A.677 – Small allenite cam cleat for spinnaker halyard.
A.488 – Small over fairlead for A.677 spinnaker halyard.
A4665 – Small wire under fairlead for spinnaker halyard cleat.
A2020LZ – 20mm dynamic stand up block for spinnaker halyard.
A4388 – Pressed lacing eye for stand up blocks and hiking strap tie-off point.
A4038 – Soft stainless steel spring for stand up block.
A.676 – Medium allenite cam cleat for jin sheets.
A.588 – Medium over fairlead for A.676 cleat.
A4152 – Bullseye fairlead for jib sheets.
A4372 – Stay adjuster for shrouds.
A2030 – 30mm dynamic block for spinnaker sheets.
A..74 – Inglefield clip for main halyard.
A4035 – P-clip for underdeck U bolt.
Helm and Transom Area
A.337 – O ring seal hatch cover.
A.338 – Rubber sealing O ring for A.337/A.337W
A4388 – Pressed lacing eye for hiking strap tie-off point.
A2160 – 60mm Pro-Ratchet for mainsheet.
A4034 – Spring for ratchet block.
A..99G – Toe strap plate.
A2030 – 30mm dynamic block for mainsheet strop.
A..22 – Small ball stopper for mainsheet strop.
A.148 – Lacing hook for elastic righting lines.
