Range / Blocks / 60mm dynamic blocks

Quint

A2069

£267.58

8 in stock (can be backordered)


By adding this item to my basket I agree I have read and understood the terms and conditions of sale.
Stockists
SKU: A2069 Category:

Description

60mm Quint Dynamic Block.



Designed for use as a low friction mainsheet system on sports catamarans, but suitable for many other applications including backstay tensioning on keelboats.



For a complete 10:1 mainsheet system, also look at A2169 – Pro-Ratchet 60mm Quint Block.



Bearings â€“ Dynamic Blocks feature our patented bearing system which uses twin rows of stainless-steel ball bearings running on a stainless-steel rail. This provides a superior load-carrying ability and longevity when compared to other bearing systems available on the market.



Swivel Lock â€“ The A2069 comes with a removable swivel lock moulding. When installed, the shackle can be locked in 90-degree orientations. When removed, the attachment shackle can spin freely.



Becket â€“ A large central hole not only reduces the overall weight of the block but also offers a rope friendly attachment point.

Reviews

There are no reviews yet.

Be the first to review “Quint”

This site uses Akismet to reduce spam. Learn how your comment data is processed.

Quint

SKUxTitlebreaking load kgfixing hole centres mmmaximum line diameter mmmaximum working load kgshackle pin mmLength mmWeight gPrice
A2060Single1000-105005117.36113£63.64
A2060CSingle Cheek Block100060105005115149£71.15
A2060TII-Single Tii-On1400-10700-8491£63.64
A2062Double1250-106005130255£131.71
A2063Double With Becket1250-106005148271£137.93
A2064Triple1250-106005130353£178.98
A2065Triple With Becket1250-106005148397£185.23
A2066Quad1250-126005130443£232.14
A2067Quad With Becket1250-106005148456£238.38
A2069Quint1250-106005130549£267.58
A2069BQuint With Becket 1250-106006150555£273.70
A2166Cheek Adaptor For 60mm Block-60---115-£7.50
